ASUS XA NB3I-E12 HGX B300 NVL8 270GB Air-Cooled (8) Intel Granite Rapids SP (2) AI Graphics Card GPU Server
$1,999,000.00
Sale price
$1,999,000.00
Regular price
Skip to product information
ASUS XA NB3I-E12 HGX B300 NVL8 270GB Air-Cooled (8) Intel Granite Rapids SP (2) AI Graphics Card GPU Server
$1,999,000.00
Sale price
$1,999,000.00
Regular price
XA NB3I-E12
9U NVIDIA HGX™ B300 8-GPU server with dual Intel® Xeon® 6 Scalable processors, designed for heavy AI workloads with 8 B300 GPU, 8 embedded CX8 Infiniband, 5 PCIe slots, 32 DIMM, 10 NVMe, dual 10Gb LAN
Key Features
- Powered by dual Intel® Xeon® 6700P processors, supporting a 350W TDP
- Seamless GPU-to-GPU interconnect via NVIDIA® NVLink™, providing 1800GB/s bandwidth for optimized scalability
- Embedded 8pcs CX8 InfiniBand on GPU, supports XDR/800G per SXM
- Modular design with minimal cable usage, enhancing assembly speed and thermal efficiency
- Integration of advanced NVIDIA technologies, leveraging the full capabilities of NVIDIA GPUs,
- NVIDIA BlueField®-3 DPUs, NVIDIA® NVLink™, NVSwitch, and networking
- Exceptional power efficiency, supported by 5+5 80 PLUS® Titanium power supplies
Processor / System Bus
2 x Socket
6th Intel® Xeon® Processor Scalable Family (Up to 350W)
6th Intel® Xeon® Processor Scalable Family (Up to 350W)
-
Memory
Total Slots:
32 (8 channel per CPU, 16 DIMM per CPU)
Capacity:
Maximum up to 4TB per CPU socket
Memory Type:
DDR5 6400 RDIMM/ 3DS RDIMM (2DPC)
Memory Size:
128GB, 96GB, 64GB
* Refer to support page for more information -
Expansion Slots
SKU1: 4 x PCIe Gen5 slots
[PCIe Switch directly]
-4 x PCIe Gen5 x16 link
SKU2: 5 x PCIe Gen5 slots
[PCIe Switch directly]
-4 x PCIe Gen5 x16 link
-1 x PCIe Gen5 x8 link (Raid Only)
*Support PCIe x16 link support DPU
** For Raid card to connect storage -
Storage
Optional Kits:
-Broadcom MegaRAID 9540-8i -
Networking
2 x 10 Gigabit LAN ports (Intel X710-AT2 Controller)
1 x Management Port -
Multi-GPU Support
NVIDIA HGX B300 288GB 8-GPU Baseboard -
Front I/O Ports
2 x USB 3.2 ports
1 x VGA port
2 x 10GbE RJ45 LAN port
1 x RJ-45 Mgmt LAN port -
Switch/LED
Front :
1 x Power Switch/LED
1 x Location Switch/LED
1 x Message LED
1 x Port80 LED (Q-Code)
LAN 1-2 LED (on NIC module) -
OS Support
Please find the latest OS support from https://servers.asus.com/support/os -
Management Solution
ASUS Control Center
On-Board ASMB12-iKVM -
Regulatory Compliance
CB, CE, FCC, BSMI -
Dimensions
945mm * 447mm * 394.5 mm -
Form Factor
9U -
Weight
Net Weight kg (CPU, DRAM & HDD not included): 120kg
Gross Weight kg(CPU, DRAM & HDD not included,
Packing include): 150kg -
Power Supply
5+5 3200W 80 PLUS Titanium Power Supply -
Environment
Operation
temperature: 10℃ ~ 35℃
Non
operation temperature: -40℃ ~ 70℃
Non
operation humidity: 20% ~ 90% ( Non condensing) -
FRU Part List
Z14PN-D32/N:90SB0E20-M0XBN0
PCIEX5-PLX-C9PB:90SC0YT0-M0XBN0
CB-C9PB:90SC0YP0-M0XBN0
PDB-C9PB:90SC0YU0-M0XBN0
BP10LE32G-25-C9PB:90SC0YQ0-M0XBN0
CB-FAN-C9PB:90SC0YR0-M0XBN0
FAN-G-C9PB:90SC0YS0-M1XBN0
FPB-C9PB:90SC0YW0-M0XBN0
PWRBRK-C9PB:90SC0Z00-M0XBN0
CB-OSFP-C2P-I:90SC0UG0-M1XBN0
CPU CARRIER KIT:90SKS000-M4EAN0
HEATSINK:90SKS000-M4JAN0
PSU:90SKP000-M4DAN0
RAIL KIT:90SKS000-MMGBN0
