Tech Specs & Customization
Processor
Two 5th Generation AMD EPYC™ 9005 Series processors with up to 192 cores per processor
Operating System
Canonical Ubuntu Server LTS
Red Hat Enterprise Linux
Accelerators
8 AMD Instinct™ MI355X 288GB 1400W OAM with AMD Infinity Fabric connectivity or
8 NVIDIA HGX B300 NVL8 270 GB 1100W SXM6 GPUs, fully interconnected with NVIDIA NVLink technology
Memory
DIMM Speed Up to 6400 MT/s
Memory Type RDIMM
Memory Module Slots 24 DDR5 DIMM slots
Maximum RAM RDIMM 6 TB max*
Storage
Front Bays Up to 16 x E3.S NVMe direct drives max 245.76 TB
Up to 10 x U.2 Gen5 NVMe SSD drives max 153.6 TB
Storage Controllers
Internal Controllers NA
Internal Boot Boot Optimized Storage Subsystem (NVMe BOSS-N1): HWRAID 1, 2 x M.2 SSDs
Security
AMD Secure Encrypted Virtualization (SEV)
AMD Secure Memory Encryption (SME)
Cryptographically signed firmware
Data at Rest Encryption (SEDs with local or external key mgmt)
Secure Boot
Secured Component Verification (Hardware integrity check)
Secure Erase
Silicon Root of Trust
System Lockdown (requires iDRAC10 Enterprise or Datacenter)
Soldered down TPM 2.0 on Mezzanine DC-SCM
Chassis Intrusion Detection
Management
Embedded / At-the-Server
iDRAC10
iDRAC Direct
iDRAC RESTful API with Redfish
iDRAC Service Module
OpenManage Software
CloudIQ for PowerEdge plug in OpenManage Enterprise
OpenManage Power Manager plugin
OpenManage Service plugin
OpenManage Update Manager plugin
Tools
Dell System Update Dell Repository Manager
Enterprise Catalogs
iDRAC RESTful API with Redfish
IPMI
RACADM CLI
OpenManage Integrations
BMC Truesight
OpenManage Integration with ServiceNow
RedHat Ansible Modules
Terraform Providers
Power Supplies
12 x 3200W Titanium 200-240 VAC, hot swap redundant
Fans
15 Standard grade GPU fans, All are hot swap fans
5 Standard grade CPU fans, All are cold swap fans
Embedded OSFP
MI355X: N/A
B300: 8x CX8 OSFP (default)
Ports
Network Options
1 x OCP 3.0 (Gen5 x8 PCIe lanes)
Front Ports
1 x iDRAC Direct (USB C) port
2 x RJ45 dedicated iDRAC Ethernet ports
1 x USB A
1 x Mini-DisplayPort
Slots
PCIe
MI355X: 12 x 75W Gen5 x16 FHHL cards
B300: 4 x 150W Gen5 x16 FHHL cards
Bezel
Optional front Security bezel
Form Factor
10U rack server
Dimensions & Weight
Height: 17.30 inches (439.50 mm)
Width: 18.98 inches (482.30 mm)
Depth: 41.12 inches (1044.70 mm) with bezel
40.27 inches (1023.00 mm) without bezel
Weight: System fully populated with MI355X GPUs – 172.3 kg (379.86 pounds)
System fully populated with B300 GPUs – 163.65 kg (360.79 pounds)
Rack Support
Static Rail
Recommended Support
